MrDocs is a C++ documentation generator for your projects.

Get started Download

No workarounds: A tool that fully understands C++

Simple code, simple documentation

MrDocs understands C++ so you can focus on keeping the code simple.

Single Source of Truth

Mr. Docs takes a specially formatted comment, called a Javadoc, which precedes a C++ declaration and renders it to form a reference as part of documentation.

It understands C++

Mr. Docs understands C++: Overload sets, private APIs, Concepts and constraints, unspecified return types, aliases, constants, SFINAE, hidden base classes, niebloids, and coroutines.

Multiple output formats

Choose from multiple output formats: Asciidoc, HTML, or XML.

Customizable

Mr. Docs is highly customizable. You can change the output format, the theme, and even the way the documentation is generated.

Examples

Examples to discover MrDocs in action.

Boost.URL

Boost.URL Antora documentation.

Boost.URL

Boost.URL multi-page Asciidoc documentation.

Boost.URL

Boost.URL single-page Asciidoc documentation.

Boost.URL

Boost.URL single-page HTML documentation.

Boost.URL

Boost.URL XML documentation.

Boost.Scope

Boost.Scope multi-page Asciidoc documentation.

Boost.Scope

Boost.Scope single-page Asciidoc documentation.

More Code, Fewer Workarounds

MrDocs let's you keep the code simple and maintainable.

  • MrDocs understands C++ features such as attributes and noexcept functions.
/** Exit the program.

    The program will end immediately.

    @note This function does not return.
*/
[[noreturn]]
void
terminate() noexcept;

terminate

Exit the program.

Synopsis

Declared in header <terminate.cpp>

void
terminate() noexcept;

Description

The program will end immediately.

Note
This function does not return.
  • Specially formatted comments are rendered to form a reference as part of documentation.
/** Return the distance between two points

    This function returns the distance between two points
    according to the Euclidean distance formula.

    @param x0 The x-coordinate of the first point
    @param y0 The y-coordinate of the first point
    @param x1 The x-coordinate of the second point
    @param y1 The y-coordinate of the second point
    @return The distance between the two points
*/
double
distance(double x0, double y0, double x1, double y1);

distance

Return the distance between two points

Synopsis

Declared in header <distance.cpp>

double
distance(
    double x0,
    double y0,
    double x1,
    double y1);

Description

This function returns the distance between two points according to the Euclidean distance formula.

Return Value

The distance between the two points

Parameters

Name Description

x0

The x-coordinate of the first point

y0

The y-coordinate of the first point

x1

The x-coordinate of the second point

y1

The y-coordinate of the second point

  • Special directives are used to describe details about the symbols.
/** Return true if a number is prime.

    @par Complexity

    Linear in n.

    @return Whether or not n is prime.
    @param n The number to test

*/
bool
is_prime(unsigned long long n) noexcept;

is_prime

Return true if a number is prime.

Synopsis

Declared in header <is_prime.cpp>

bool
is_prime(unsigned long long n) noexcept;

Description

Linear in n.

Return Value

Whether or not n is prime.

Parameters

Name Description

n

The number to test

  • It understands concepts, constraints and SFINAE.
#include <type_traits>
#include <stdexcept>

/** Computes the square root of an integral value.

    This function calculates the square root of a
    given integral value using bit manipulation.

    @throws std::invalid_argument if the input value is negative.

    @tparam T The type of the input value. Must be an integral type.
    @param value The integral value to compute the square root of.
    @return The square root of the input value.
 */
template <typename T>
std::enable_if_t<std::is_integral_v<T>, T> sqrt(T value) {
    if (value < 0) {
        throw std::invalid_argument(
            "Cannot compute square root of a negative number");
    }
    T result = 0;
    // The second-to-top bit is set
    T bit = 1 << (sizeof(T) * 8 - 2);
    while (bit > value) bit >>= 2;
    while (bit != 0) {
        if (value >= result + bit) {
            value -= result + bit;
            result += bit << 1;
        }
        result >>= 1;
        bit >>= 2;
    }
    return result;
}

sqrt

Computes the square root of an integral value.

Synopsis

Declared in header <sqrt.cpp>

template<typename T>
std::T
sqrt(T value);

Description

This function calculates the square root of a given integral value using bit manipulation.

Exceptions

Name Thrown on

if

the input value is negative.

Return Value

The square root of the input value.

Template Parameters

Name Description

T

The type of the input value. Must be an integral type.

Parameters

Name Description

value

The integral value to compute the square root of.
